How to Migrate Data from MySQL to ClickHouse®

Introduction

As applications grow, traditional relational databases such as MySQL may struggle with analytical workloads involving millions of records and complex aggregations. While MySQL excels at Online Transaction Processing (OLTP), ClickHouse® is purpose-built for Online Analytical Processing (OLAP), enabling lightning-fast analytical queries on large datasets.

Migrating data from MySQL to ClickHouse® allows organizations to build high-performance reporting systems, dashboards, and real-time analytics without impacting transactional workloads.

In this blog, you'll learn several approaches to migrate data from MySQL to ClickHouse®, along with their advantages, limitations, and best use cases.

Why Migrate from MySQL to ClickHouse®?

MySQL and ClickHouse® are designed for different workloads.

Feature	MySQL	ClickHouse®
Storage model	Row-based	Columnar
Best for	Transactions (OLTP)	Analytics (OLAP)
Query speed	Fast for row reads	Extremely fast for scans
Aggregation speed	Moderate	Extremely fast
Scalability	Vertical	Horizontal
Use Cases	Best for applications	Best for reporting and analytics

Migration from MySQL to ClickHouse® makes sense when:

Analytical queries are becoming slow on MySQL.
You need real-time dashboards over large datasets.
Reporting queries are impacting your production database.
You are processing millions or billions of rows regularly.

Migration Architecture

                                    MySQL
                                      │
                                      ▼
                                Export / Sync
                                      │
                                      ▼
                              Data Transformation
                                      │
                                      ▼
                                 ClickHouse®
                                      │
                                      ▼
                             Dashboards / Analytics

Migration Methods

There are several ways to migrate data from MySQL to ClickHouse®.

Method 1: CSV Export and Import (Recommended for Beginners)

This is the most straightforward approach for a one-time bulk migration of historical data.

Step 1: Export Data from MySQL as CSV

-- Run in MySQL
SELECT *
INTO OUTFILE '/tmp/employees.csv'
FIELDS TERMINATED BY ','
ENCLOSED BY '"'
LINES TERMINATED BY '\n'
FROM employees;

Alternatively, use the mysql CLI:

mysql -u root -p mydb \
  -e "SELECT * FROM employees" \
  | sed 's/\t/,/g' > /tmp/employees.csv

Step 2: Create the Target Table in ClickHouse®

Before importing data, create the corresponding MergeTree table in ClickHouse®. Note that MySQL data types need to be mapped to ClickHouse® equivalents.

CREATE TABLE employees
(
    id          UInt32,
    name        String,
    department  String,
    salary      Float64
)
ENGINE = MergeTree
ORDER BY id;

Step 3: Import CSV into ClickHouse®

Using clickhouse-client:

clickhouse-client \
  --query "INSERT INTO employees FORMAT CSV" \
  < /tmp/employees.csv

Using the HTTP API:

curl -u default:password \
  "http://localhost:8123/?query=INSERT+INTO+default.employees+FORMAT+CSV" \
  --data-binary @/tmp/employees.csv

Step 4: Verify the Import

SELECT count() FROM default.orders;

Output:

count()
5

Method 2: Using the MySQL Table Engine

ClickHouse® can directly query MySQL tables without importing data. Furthermore, this approach allows you to copy data entirely within ClickHouse® using a single command.

Step 1: Create MySQL Engine Table

CREATE TABLE mysql_employees
(
    id          UInt32,
    name        String,
    department  String,
    salary      Float64
)
ENGINE = MySQL(
    'localhost:3306',   -- MySQL host and port
    'mydb',             -- MySQL database name
    'employees',        -- MySQL table name
    'readonly_user',    -- MySQL username
    'password'          -- MySQL password
);

Now you can query the MySQL table directly:

SELECT * FROM mysql_employees;

Step 2: Create the MergeTree Storage Table

CREATE TABLE employees
(
    id          UInt32,
    name        String,
    department  String,
    salary      Float64
)
ENGINE = MergeTree
ORDER BY id;

Step 3: Copy Data in One Command

Once the MySQL engine is configured, migrate the data using INSERT INTO ... SELECT:

INSERT INTO employees
SELECT *
FROM mysql_employees;

This is useful for quickly copying an entire table.

Step 4: Verify

SELECT *
FROM employees
LIMIT 5;

This is the recommended approach for most one-time migrations as it is clean, fast, and entirely within ClickHouse®.

Method 3: Using ClickPipes (ClickHouse Cloud)

For ClickHouse Cloud users, ClickPipes provides a fully managed data ingestion service. The migration process is straightforward:

Create a ClickPipe
Connect your MySQL database
Select the tables to synchronize
Start continuous replication

Advantages:

Managed service
Incremental synchronization
Minimal maintenance

Limitations:

Available only in ClickHouse Cloud

Method 4: Real-Time Migration Using Kafka

For continuous real-time synchronization between MySQL and ClickHouse®, Change Data Capture (CDC) with Debezium is the most robust approach. It captures every INSERT, UPDATE, and DELETE in MySQL and streams them into ClickHouse® via Kafka.

Architecture

                                  MySQL (Source)
                                       │
                                       ▼
                            Debezium (captures changes)
                                       │
                                       ▼
                               Kafka (event stream)
                                       │
                                       ▼
                             ClickHouse® Kafka Engine
                                       │
                                       ▼
                                Materialized View
                                       │
                                       ▼
                                 MergeTree Table

This approach continuously replicates MySQL changes into ClickHouse®.

Best suited for:

Event streaming
Real-time dashboards
IoT
Monitoring systems

Setting up Debezium is covered in detail in a separate blog.

MySQL to ClickHouse® Data Type Mapping

MySQL Type	ClickHouse® Type
INT	Int32 or UInt32
BIGINT	Int64 or UInt64
VARCHAR(n)	String
TEXT	String
DECIMAL(p,s)	Decimal(p,s)
FLOAT	Float32
DOUBLE	Float64
DATETIME	DateTime
DATE	Date
TINYINT(1)	UInt8 (Bool)
JSON	String

Verify the Migration

After migrating data, always verify that the row counts and aggregations match between MySQL and ClickHouse®.

Row count check:

-- MySQL
SELECT COUNT(*) FROM orders;

-- ClickHouse®
SELECT count() FROM default.orders;

Both queries should return identical results. If they don't, check for data type mismatches, NULL handling differences, or missing rows during export.

Best Practices

Schema Design Tips for Migration

1. Choose the right ORDER BY

Unlike MySQL's primary key, ClickHouse®'s ORDER BY determines the physical sort order of data. Choose columns you frequently filter on:

ORDER BY (country, status, order_date)

2. Use LowCardinality for string columns

Columns like country and status have few distinct values. Wrapping them with LowCardinality improves compression and query speed:

country LowCardinality(String),
status  LowCardinality(String)

3. Partition by time

For time-series or date-based data, always partition by month or day:

PARTITION BY toYYYYMM(order_date)

4. Drop AUTO_INCREMENT

MySQL's AUTO_INCREMENT primary key has no equivalent in ClickHouse®. Use UInt32 or UInt64 for ID columns without any auto-increment behavior.

5. Handle NULLs carefully

ClickHouse® columns are NOT NULL by default. If your MySQL table has nullable columns, either use Nullable(Type) in ClickHouse® or replace NULLs with default values during migration:

-- Replace NULL with a default value during migration
SELECT
    id,
    COALESCE(department, 'Unknown') AS department
FROM default.mysql_employees;

Common Challenges

Data Type Mismatches Ensure compatible data types between MySQL and ClickHouse® using the mapping table above.

Duplicate Data Use primary keys or deduplication strategies when performing incremental loads.

Large Tables Split large datasets into batches to avoid excessive memory usage.

Character Encoding Ensure UTF-8 encoding for consistent text representation.

Performance Tips

Use the MergeTree engine for analytical workloads.
Use batch inserts instead of inserting rows individually.
Compress data during migration.
Choose a suitable partitioning strategy.
Avoid unnecessary indexes - ClickHouse® relies on sorting and data skipping indexes instead.

Quick Reference

Scenario	Recommended Method
One-time migration	CSV Export and Import
Direct access to MySQL	MySQL Table Engine
Full table migration	INSERT INTO ... SELECT
Continuous synchronization	ClickPipes
Real-time streaming	Kafka + Debezium

Final Thoughts

Migrating data from MySQL to ClickHouse® is a practical step for teams that need faster analytical queries without replacing their existing transactional database. MySQL continues to handle application writes and transactional operations, while ClickHouse® takes over the heavy analytical workload.

For most teams, the INSERT INTO ... SELECT approach via the MySQL engine is the simplest and most reliable method for a one-time migration. For real-time continuous sync, Debezium CDC provides a robust and production-ready solution.

With the right schema design and migration approach, ClickHouse® can dramatically improve your analytical query performance from day one.
